停車棚鋼梁安裝過程

Installation process of steel beam of parking shed

裝配式輪胎骨架生產→鋼梁裝配→鋼梁焊接→焊縫探傷→焊縫補漆→鋼梁裝配→測量校正→焊接。

Fabricated tire frame production → steel beam assembly → steel beam welding → weld flaw detection → weld repair → steel beam assembly → measurement and correction → welding.

分段鋼梁長度適中時，由履帶完成安裝，點設在鋼梁1/3分段點處。

When the length of the segmented steel beam is moderate, the installation is completed by the crawler, and the installation point is set at the 1 / 3 segmented point of the steel beam.

裝配完成后，鋼梁跨度比較大，用兩個履帶吊起，設置4個點，保證裝配力方向的延長線與1/鋼梁的3段點。

After assembly, the span of the steel beam is relatively large. Lift it with two crawlers and set four points to ensure that the extension line in the direction of assembly force is consistent with the three section points of 1 / steel beam.

確定鋼梁的安裝位置和方向后，將梁慢慢下放到安裝點，使梁穩定就位。橫梁與牛腿對正后，用沖釘臨時定位定心，對正橫梁兩端。擰緊拉直，臨時擰緊節點兩側的螺栓。

After determining the installation position and direction of the steel beam, slowly lower the beam to the installation point to stabilize the beam in place. After the beam is aligned with the bracket, use punch nails to temporarily locate and center, and align both ends of the beam. Tighten and straighten, and temporarily tighten the bolts on both sides of the node.

停車棚鋼梁生產工段

Steel beam production section of parking shed

根據現場安裝要求，鋼梁生產分為3個生產工段。

According to the site installation requirements, the steel beam production is divided into three production sections.

先制作板加區的X1線，包括11根車梁、13根立柱和屋頂托梁等，約6T。加熱爐，梁42根（其中Q345C14根，Q235B28根），立柱、頂梁、支架、檁條等32根。板內有車梁55根、立柱39根和頂梁、支架、檁條等加區域（X1軸除外）。鋼柱上柱為H型實腹式，下柱為雙臂分離式，肩梁采用單腹板形式。

First, make X1 line of slab processing area, including 11 vehicle beams, 13 columns and roof joists, about 6T. Heating furnace, 42 beams (including q345c14 and q235b28), 32 columns, top beams, supports and purlins. There are 55 car beams, 39 upright columns, top beams, supports, purlins and other additional areas in the plate (except X1 axis). The upper column of the steel column is H-shaped solid web type, the lower column is double arm separated type, and the shoulder beam adopts the form of single web.

上下立柱設有K型管支撐，柱腳為獨立柱腳。轎廂梁跨度為H型截面實腹型15M、18M、24M、27M，梁高2M、2.2M、2.5M、2.8M、3M。車梁與水平制動梁、輔助桁架和下部水平支撐構成一個整體。屋面梁采用H型實心腹梁，間距42M，大柱間距處加托梁。

The upper and lower columns are provided with K-shaped pipe support, and the column base is an independent column base. The car beam span is H-section solid web type, 15m, 18m, 24m and 27m, and the beam height is 2m, 2.2M, 2.5m, 2.8m and 3M. The vehicle beam is integrated with the horizontal brake beam, auxiliary truss and lower horizontal support. The roof beam adopts H-shaped solid web beam with a spacing of 42m, and joists are added at the spacing of large columns.

此外，如果濟南停車棚想要長年使用的話，建議不要因?yàn)橄牍?jié)約一點成本而購買一些低質量的膜材料。膜壞是可以再換，但是期間換膜的成本和人工費，不膜結構車棚質量會大打，而且還會浪費很多工程費用。也不需要購買貴的材料，如果膜材料質量相差不大的的話，建議購買相對價格較低的那。

In addition, if Jinan parking shed wants to be used for a long time, it is recommended not to buy some low-quality membrane materials because you want to save a little cost. If the membrane is broken, it can be replaced again, but the cost and labor cost of replacing the membrane during the period will not only affect the quality of the membrane structure shed, but also waste a lot of engineering costs. There is no need to buy expensive materials. If the quality of membrane materials is not different, it is recommended to buy the one with lower relative price.

要避免購買到偽膜材料，膜材樣品，在膜材料運至工地至少要派一個自己的人到現場監督。準備施工驗收的時候，和車棚的膜結構公司要膜材料的質檢報告。

To avoid purchasing false membrane materials and membrane samples, at least one person shall be sent to the site for supervision when the membrane materials are transported to the construction site. When preparing for construction acceptance, ask the membrane structure company of the shed for the quality inspection report of membrane materials.

本公司是一家集雨棚、停車棚、遮陽棚等產品設計生產安裝服務為一體的公司。公司經過潛心研究，吸收行業經驗，開發出各類高水平鋼結構。更多相關內容就來我們網站www.jyxingyu.com關注咨詢了解吧！

The company is a company integrating the design, production and installation services of canopy, parking shed, sunshade and other products. After painstaking research and absorbing industry experience, the company has developed all kinds of high-level steel structures. For more information, please visit our website at www.jyxingyu.com Com follow the consultation to understand!
